Leak Testing Machine

Name: Leak Testing Machine Manufacturer in India | Pune
Price: 150000.00 INR
Availability: InStock

About the Leak Testing Machine

A leak testing machine seals a component, pressurises it and measures whether pressure holds — quantifying a leak rate instead of relying on a bubble test. The cycle runs in three timed phases, and getting the stabilisation phase right is most of what separates a reliable rig from a noisy one.

Key Features

Fill, stabilise and test phases each timed to the component volume
Leak rate reported in cc/min against a defined reject limit
Differential pressure arrangement available to cancel ambient temperature drift
Sealing fixture designed to seal every opening repeatably without distorting the part
Verified with a calibrated master leak, proving the fixture as well as the instrument

Ideal For / Applications

Automotive castings, housings and covers
Cylinder heads, blocks and oil pans
Water pumps, radiators and heat exchangers
Fuel and brake components
Sealed electrical enclosures and connectors

Frequently Asked Questions

Why does a leak test need a stabilisation time?

Filling compresses and warms the air, and that heat then dissipates into the component walls, dropping pressure for reasons unrelated to any leak. Stabilisation lets the transient settle. Cutting it to save cycle time is the most common cause of good parts being rejected.

How do you verify the machine is working?

With a calibrated master leak — a reference orifice of known rate fitted to a good part. That proves the whole system including the sealing fixture, not just the instrument, and is normally run at shift start and after any seal change.

Why is the sealing fixture so important?

Because most leak test failures are fixture failures. The fixture must seal every opening repeatably without distorting the part and present the same internal volume every cycle, since leak rate is calculated from volume.

Need this machine for your component?

Send us the component drawing and joint specification. VR Automation quotes against your part, not a catalogue.

Test medium	Water/Vacuum/Air
Test pressure	0-50 bar
Test method	Flow measurement
Application	Plastic/Automotive/Metal/Fuel/Tube Pipe
Material	Stainless Steel
Machine Type	Leak Testing
Leak rate range	1e-5 mbar l/s
Automation Grade	Automatic
